Stolt Steel, located in Dubai, UAE, specializes in providing top-notch carbon-steel line pipes, including the API 5L X52 PSL2 pipes, to a diverse range of clients in the oil, gas, water, and industrial sectors. Their X52 PSL2 pipes come in both seamless and welded options, crafted under stringent quality controls and international standards to guarantee reliable performance in challenging pipeline and infrastructure projects.
CS API 5L X52 PSL 2 Pipes Exporter in UAE, Carbon Steel API 5L X52 PSL 2 Pipes Price List in Dubai, Carbon Steel API 5L X52 PSL 2 Pipes Supplier in Ajman, Carbon Steel API 5L X52 PSL 2 Pipes Exporter in Dubai, CS API 5L X52 PSL 2 Pipes Exporter in Dubai, CS API 5L X52 PSL 2 Pipes Size Chart, Carbon Steel API 5L X52 PSL 2 Pipes Price in Jebel Ali, Carbon Steel API 5L X52 PSL 2 Pipes Weight Chart, CS API 5L X52 PSL 2 Pipes Thickness, Carbon Steel API 5L X52 PSL 2 Pipe Supplier in Sharjah, Carbon Steel API 5L X52 PSL 2 Pipes Stockist in Ajman
Table of Contents
Carbon Steel API 5L X52 PSL 2 Pipes Supplier in Dubai, Carbon Steel API 5L X52 PSL 2 Pipes Exporter in Ajman, CS API 5L X52 PSL 2 Pipes Sizes in mm, CS API 5L X52 PSL 2 Pipe Stockist in Dubai, Carbon Steel API 5L X52 PSL 2 Pipes Price List in Sharjah, CS API 5L X52 PSL 2 Pipes Distributor in Dubai, Carbon Steel API 5L X52 PSL 2 Pipes in Jebel Ali, Carbon Steel API 5L X52 PSL 2 Pipes Supplier in Dubai, Carbon Steel API 5L X52 PSL 2 Pipes Distributor in UAE
What is Carbon Steel API 5L X52 PSL 2 Pipes ?
When it comes to the chemical makeup of API 5L X52 PSL2 carbon-steel pipes, you can typically expect carbon (C) levels of up to about 0.24%, manganese (Mn) up to around 1.4%, phosphorus (P) capped at 0.025%, sulfur (S) at 0.015% or less, and carefully regulated amounts of alloying or micro-alloying elements like vanadium (V), niobium (Nb), and titanium (Ti). There are also limits on copper, nickel, chromium, and molybdenum when specified. In terms of mechanical properties, these pipes boast a minimum yield strength of around 320 MPa and a tensile strength starting at roughly 435 MPa, along with sufficient elongation and impact toughness to ensure safety and reliability under pressure.
Carbon Steel API 5L X52 PSL 2 Pipes Chemical Composition
| Carbon Steel Grade | Mass fraction, % based on heat and product analyses | Carbon Equiv a | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| C | Si | Mn | P | S | V | Nb | Ti | Other | CE IIW | CE Pcm | |||||||||||
| max b | max | max b | max | max | max | max | max | max | max | ||||||||||||
| X52N | 0.24 | 0.45 | 1.4 | 0.025 | 0.015 | 0.1 | 0.05 | 0.04 | d,e,l | 0.43 | 0.25 | ||||||||||
Carbon Steel API 5L X52 PSL 2 Pipes Mechanical Properties
| Pipe Grade | Tensile Properties – Pipe Body of SMLS and Welded Pipes PSL 2 | Seam of Welded Pipe | |||||
|---|---|---|---|---|---|---|---|
| Yield Strength a | Tensile Strength a | Ratio a,c | Elongation | Tensile Strength d | |||
| Rt0,5 PSI Min | Rm PSI Min | R10,5IRm | (in 2in) | Rm (psi) | |||
| Af % | |||||||
| Minimum | Maximum | Minimum | Maximum | Maximum | Minimum | Minimum | |
| X52 | 52,200 | 76,900 | 66,700 | 110,200 | 0.93 | f | 66,700 |
| API 5L X52 Pipe types | API 5L X52 Pipe Size (mm) | Tolerances | |
|---|---|---|---|
| Hot rolled API 5L X52 Seamless Pipe | OD | <50 | ±0.50mm |
| ≥50 | ±1% | ||
| WT | <4 | ±12.5% | |
| ≥4～20 | +15%, -12.5% | ||
| >20 | ±12.5% | ||
| Cold drawn API 5L X52 Seamless Pipe | OD | 6～10 | ±0.20mm |
| 10～30 | ±0.40mm | ||
| 30～50 | ±0.45 | ||
| >50 | ±1% | ||
| WT | <1 | ±0.15mm | |
| >1～3 | + 15%, – 10% | ||
| >3 | + 12.5%, – 10% | ||
Carbon Steel API 5L X52 PSL 2 Pipes Specification
| Grade of material | X52 / L390 (N, M, Q, R) |
| X52 Steel LSAW / DSAW | 16’OD TO 54″ OD (8 MM TO 50 MM THK) |
| Standard | ISO 3183 L390/ API 5L X52 |
| API 5L X52 Seamless Pipe (OD) | 21.3 – 660mm ( Inch 1/2” – 26”) |
| X52 SAW | 16″ – 100″ NB |
| API 5L X52 PSL2 ERW and HFW | 1/2” NB – 24” NB |
| API 5L X52 PSL2 Pipe end | Square Cut, Chamfering, Grooved, Buttweld, Thread Cutting, Squared Ends, Deburring, Flanged Ends, Beveled End (BE), Socket, Cut Grooves, Vibrator Grinding, Coupling, Plain end (PE), Threaded Ends (Male & Female), Pub Joints, Screwed |
| Origin of X52 material | European, Chinese, Africa, Gulf, Asian, UAE, Russian, American, Japan, UAEraine, Japanese, Indian, USA, Latin-American, Korean, |
| API 5L X52 Wall Thickness | SCH-STD, SCH160, SCH-XXS, SCH40, SCH-XS, SCH80 |
| Equivalent Standards | JIS, ANSI, EN, DIN, IS, UNI, ISO, AWWA, SS, AISI, NFA, BS, GOST, SA, KS, API, C ASTM, SAE, GB, |
| PSL Level | |
| Coating for API 5L X52 Line Pipe | Galvanized, 3PP, Varnished, 3LPE, lined pipe, Black Painting, 3PE, CRA clad, FBE, Anti-Rust Oil |
Carbon Steel API 5L X52 PSL 2 Pipes Dimension
If You Are Looking To Buy High Quality Pipes, Sheet, Angle, Hollow Section, Flat Product.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Carbon Steel API 5L X52 PSL 2 Pipes Exporter in UAE, Carbon Steel API 5L X52 PSL 2 Pipes Price List in Dubai, CS API 5L X52 PSL 2 Pipes Supplier in Ajman, Carbon Steel API 5L X52 PSL 2 Pipes Exporter in Dubai, CS API 5L X52 PSL 2 Pipes Exporter in Dubai, Carbon Steel API 5L X52 PSL 2 Pipes Size Chart, CS API 5L X52 PSL 2 Pipes Price in Jebel Ali, Carbon Steel API 5L X52 PSL 2 Pipes Weight Chart, Carbon Steel API 5L X52 PSL 2 Pipes Thickness, CS API 5L X52 PSL 2 Pipes Supplier in Sharjah, API 5L X52 PSL 2 Pipes Stockist in Ajman
Stolt Steels is the largest stockist of Carbon Steel API 5L X52 PSL 2 Pipes in Dubai, UAE.
Stolt Steels is a trusted stockist, stockist, and supplier of premium-quality steel products in Dubai, UAE, serving diverse industrial sectors with reliable materials and timely delivery. With a strong commitment to excellence, we offer a wide range of pipes, sheets, plates, and other metal solutions designed to meet global standards. Our extensive inventory, expert support, and customer-focused approach make us a preferred partner for companies seeking durable and high-performance steel products. For inquiries or orders, contact us at sales@stoltsteels.com.
Types of Carbon Steel API 5L X52 PSL 2 Pipes
Uses of Carbon Steel API 5L X52 PSL 2 Pipes
API 5L X52 PSL2 pipes are commonly utilized for transporting oil, gas, and water throughout upstream, midstream, and downstream pipelines, including gathering lines, transmission pipelines, and distribution networks. Their impressive strength, toughness, weldability, and adherence to strict testing standards make them ideal for long-distance pipelines, offshore and onshore energy projects, hydrocarbon transportation lines, and industrial fluid systems where durability, reliability, and compliance with safety standards are absolutely essential.
