Grade B Inverted Angle Stockist and Supplier in Dubai, UAE

Home >Inverted Angle > Grade B Inverted Angle

Stolt Steel, located in Dubai, UAE, provides a solid range of marine-grade structural steel products, including the Grade B Inverted Angle, which is specifically crafted for shipbuilding and offshore construction. As a dedicated supplier, they offer hot-rolled inverted-angle steel sections that meet international classification society standards, ensuring dependable structural components for hull framing, support structures, and reinforcement. Their Grade B inverted angles come in various sizes and leg-thickness combinations, giving you the flexibility needed for a wide array of marine and industrial fabrication projects. Stolt Steel prides itself on quality, precision, and timely delivery, making it a go-to source for high-strength steel solutions in challenging maritime environments.

Grade B Inverted Angle stockist in UAE, Grade B Inverted Angle supplier in Dubai, Grade B Inverted Angle exporter in Abu Dhabi, Grade B Inverted Angle stockist in Sharjah, ABS certified Grade B marine inverted angle UAE, shipbuilding Grade B inverted angle Dubai, offshore structural Grade B inverted angle Abu Dhabi, hot rolled Grade B angle profile Sharjah, marine hull Grade B inverted angle UAE, Grade B approved ship steel Dubai.

Grade B Inverted Angle price in UAE, Grade B inverted angle size chart Dubai, Grade B angle distributor Abu Dhabi, Grade B marine steel angle stock Sharjah, Grade B offshore platform angle UAE, Grade B structural angle bar supplier Dubai, Grade B shipyard-grade steel Abu Dhabi, Grade B hull structure inverted angle Sharjah, Grade B certified steel ABS / DNV / LR UAE, Grade B structural angle availability Dubai.

What is Grade B Inverted Angle?

Grade B Inverted Angle typically meets marine-steel specifications like ABS or RMRS. In terms of composition, it contains carbon ≤0.21%, silicon ≤0.35%, manganese 0.8–1.2%, and both phosphorus and sulfur at ≤0.035%. On the mechanical side, it boasts a minimum yield strength of around 235 MPa, tensile strength ranging from 400 to 520 MPa, and an elongation of about 22%, striking a balance between strength, ductility, and toughness. The impact properties, often confirmed through Charpy-V tests at 0 °C, guarantee reliable performance in harsh marine conditions and heavy-load applications, making it perfect for critical structural components.

Grade B Inverted Angle Specifications


Carbon (C) — max	≤ 0.21%
Silicon (Si) — max	≤ 0.35%
Manganese (Mn)	~ 0.80 – 1.20%
Phosphorus (P) — max	≤ 0.035%
Sulfur (S) — max	≤ 0.035%
Yield Strength (min)	≥ 235 MPa
Tensile Strength (Rm)	400 – 520 MPa
Elongation (min)	~ 22%
Impact Toughness (Charpy V‑notch)	Tested at 0 °C, min ~ 27 J
Typical Forms / Sizes	Unequal‑leg / inverted angles; various leg sizes and thicknesses
Delivery / Treatment	Hot-rolled, control-rolled / as-rolled; mill-certified for marine use

Grade B Inverted Angle Chemical Compositions


Carbon (C) — max	≤ 0.21%
Silicon (Si) — max	≤ 0.35%
Manganese (Mn) — typical / min	~ 0.80 – 1.20%
Phosphorus (P) — max	≤ 0.035%
Sulfur (S) — max	≤ 0.035%
Copper (Cu) — optional	≤ 0.35%
Chromium (Cr) — optional	≤ 0.30%
Nickel (Ni) — optional	≤ 0.30%

Grade B Inverted Angle Equivalent Grades


American / ASTM	ASTM A36, ASTM A131 Grade B (plate/angle equivalent)
British / BS	BS 4360 Grade 43A (older) / BS EN 10025 S275JR
Japanese / JIS	JIS G3101 SS400, sometimes SM400B
Chinese / GB	GB/T 700 Q235B, GB/T 1591 Q345B (depending on thickness and strength)
European / EN	EN 10025 S275JR, S275JO (for mild structural steel)
German / DIN	DIN 17100 St37-2
Classification Society	Recognized as ABS Grade B, DNV Grade B, LR Grade B, BV Grade B (angle/plate)

If You Are Looking To Buy High Quality Pipes, Sheet, Angle, Hollow Section, Flat Product.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

Buy Grade B Inverted Angle in UAE, Grade B steel inverted angle importer Dubai, Grade B angle steel stockist Abu Dhabi, Grade B marine grade inverted angle supplier Sharjah, Grade B angle for shipbuilding UAE, oil & gas Grade B offshore structural steel Dubai, Grade B fabrication and welding steel Abu Dhabi, Grade B ship repair angle material Sharjah, Grade B ready stock for marine construction UAE, top Grade B shipbuilding steel supplier in Dubai.

Stolt Steels is the largest stockist of Grade B Inverted Angle in Dubai, UAE.

Stolt Steels is a trusted stockist, stockist, and supplier of premium-quality steel products in Dubai, UAE, serving diverse industrial sectors with reliable materials and timely delivery. With a strong commitment to excellence, we offer a wide range of pipes, sheets, plates, and other metal solutions designed to meet global standards. Our extensive inventory, expert support, and customer-focused approach make us a preferred partner for companies seeking durable and high-performance steel products. For inquiries or orders, contact us at sales@stoltsteels.com.
