Manganese Steel Plates Stockist and Supplier in Dubai, UAE
Home > Heat Resistant Steel Plates > Manganese Steel Plates
Manganese steel plates, often referred to as Hadfield steel, are a type of high-manganese alloy steel celebrated for their remarkable toughness, hardness, and resistance to wear. These plates typically contain about 11–14% manganese, which gives them outstanding work-hardening properties. This means that when they face impact, the surface becomes incredibly hard while the core remains tough and ductile. Because of these qualities, manganese steel plates are perfect for situations that involve heavy impacts, abrasion, and high-stress conditions, as they effectively resist deformation, cracking, and wear over time.
Manganese Steel Plates, High Manganese Steel Plate, Hadfield Manganese Plates, Manganese Steel Sheets Supplier, Manganese Steel Plate Exporter, Wear Resistant Manganese Plates Dubai, Manganese Steel Plate Stockist UAE, Impact Resistant Steel Plates Abu Dhabi, Manganese Plate Supplier Sharjah, Abrasion Resistant Manganese Steel UAE.
Table of Contents
Quenched Manganese Steel Plates, Work Hardening Steel Plates, High Strength Manganese Sheets, Manganese Alloy Plates Dubai, Crusher Liner Steel Plates UAE, Mining Equipment Manganese Plates Abu Dhabi, Manganese Wear Plates Sharjah, Structural Manganese Steel UAE, Industrial Manganese Steel Sheets Dubai.
What is Manganese Steel Plates?
The chemical makeup of manganese steel plates usually includes carbon (0.8–1.25%), manganese (11–14%), along with trace amounts of silicon, phosphorus, and sulfur. This blend allows the steel to absorb significant shocks, resist wear, and keep its structural integrity even in extreme conditions. On a mechanical level, these plates boast high tensile strength, excellent impact resistance, and notable toughness, with a unique ability to harden further when subjected to repeated impacts or stress.
Manganese Steel Plates Specifications
| Parameter | Specification |
|---|---|
| Material Grade | Hadfield / High Manganese Steel (Mn 11–14%) |
| Standard | ASTM A128 / IS 2633 / EN 1561 / JIS G4801 |
| Tensile Strength | 850–1000 MPa |
| Yield Strength | 400–600 MPa |
| Hardness | 200–220 HB (as-rolled), can increase to 500–600 HB after work-hardening |
| Elongation | 35% min |
| Manganese Content | 11–14% |
| Carbon Content | 0.8–1.25% |
| Thickness Range | 6–150 mm (typical) |
| Width | 1000–2000 mm (typical) |
| Length | As per customer / mill standard |
| Surface Finish | Hot-rolled, rough finish |
Manganese Steel Plates Chemical Compositions
| Element | Composition (%) |
|---|---|
| Carbon (C) | 0.80 – 1.25 |
| Manganese (Mn) | 11.0 – 14.0 |
| Silicon (Si) | 0.30 – 1.00 |
| Phosphorus (P) | 0.040 max |
| Sulphur (S) | 0.040 max |
| Chromium (Cr) | 0.20 – 0.40 (optional) |
| Molybdenum (Mo) | 0.06 – 0.10 (optional) |
| Nickel (Ni) | 0.20 – 0.40 (optional) |
| Others | Residuals as per ASTM / EN foundry steel limits |
Manganese Steel Plates Equivalent Grades
| Standard | Equivalent Grade | Notes |
|---|---|---|
| ASTM (USA) | ASTM A128 Grade A / B2 / C | Most common Mn steel casting/plate standard |
| DIN / EN (Europe) | X120Mn12 / 1.3401 | Widely used European high-Mn wear-resistant steel |
| British (BS) | BS 3100 BW10 | Work-hardening manganese steel grade |
| Japanese (JIS) | JIS G4801 SCMnH11 | High-manganese impact-resistant steel |
| Chinese (GB) | GB/T 5680 ZGMn13 / ZGMn13-1 | 13% Mn wear-resistant steel |
| Indian (IS) | IS 276 Grade 1 / Grade 2 | High-manganese steel for wear applications |
If You Are Looking To Buy High Quality Pipes, Sheet, Angle, Hollow Section, Flat Product.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Heavy-Duty Manganese Steel UAE, Impact Protection Steel Plates Dubai, Rock Crusher Manganese Plates Abu Dhabi, Excavator Bucket Manganese Steel Sharjah, Offshore & Mining Steel UAE, Construction Grade Manganese Plates Dubai, Engineering Manganese Steel Abu Dhabi, Manganese Steel Supplier UAE, Manganese Sheet Stockist Sharjah.
Stolt Steels is the largest stockist of Manganese Steel Plates in Dubai, UAE.
Stolt Steels is a trusted stockist, stockist, and supplier of premium-quality steel products in Dubai, UAE, serving diverse industrial sectors with reliable materials and timely delivery. With a strong commitment to excellence, we offer a wide range of pipes, sheets, plates, and other metal solutions designed to meet global standards. Our extensive inventory, expert support, and customer-focused approach make us a preferred partner for companies seeking durable and high-performance steel products. For inquiries or orders, contact us at sales@stoltsteels.com.
Types of Manganese Steel Plates
Uses of Manganese Steel Plates
Industries like mining, construction, and material handling widely utilize manganese steel plates due to their exceptional wear resistance and durability. You’ll often find them in applications such as liners for crushers, screens, and hoppers, wear plates for heavy machinery, earth-moving equipment, railway track work, and components in cement plants. Their capacity to endure severe impacts, abrasion, and high-stress environments makes manganese steel plates a go-to choice for critical components that face constant mechanical wear and heavy loads.
