ASME SA 516 Gr.65 Plate Stockist and Supplier in Dubai, UAE
Home > ASME SA 516 Gr.65 Plate
Stolt Steel stands out as a trusted stockist and supplier of ASME SA 516 Grade 65 steel plates right in Dubai, UAE. They provide top-notch pressure vessel steel that’s perfect for high-pressure and high-temperature applications. Renowned for their commitment to quality, Stolt Steel delivers steel plates that boast exceptional weldability, durability, and resistance to brittle fracture. SA 516 Gr. 65 is particularly noted for its enhanced toughness and superior performance compared to lower grades in the same family. With rigorous quality controls, deep industry knowledge, and a focus on customer satisfaction, Stolt Steel guarantees reliable solutions for the demanding needs of the oil and gas, petrochemical, power generation, and refinery sectors.
ASME SA 516 Gr.65 Pressure Vessel Steel Plates Dubai UAE, ASTM A516 Grade 65 Boiler Quality Plates Abu Dhabi, SA516 Gr.65 Carbon Steel Plates Sharjah, Hot Rolled SA516 Grade 65 Steel Plates Ajman, and ASME SA 516 Gr.65 Pressure Vessel Plates Jebel Ali. These keywords are ideal for refineries, boilers, petrochemical storage, and industrial fabrication requirements.
Table of Contents
ASME SA516 Gr.65 Low-Temperature Service Plates Ras Al Khaimah, SA516 Grade 65 High Tensile Plates Al Ain, ASTM A516 Gr.65 Boiler Steel Plates United Arab Emirates, Fabrication Ready ASME SA516 Gr.65 Steel Plates Dubai, and Heat Resistant SA516 Gr.65 Plates Abu Dhabi. These terms highlight performance in pressure applications, weldability, and reliability.
What is ASME SA 516 Gr.65 Plate
When it comes to composition, ASME SA 516 Grade 65 includes Carbon at 0.23–0.26%, Manganese at 0.60–1.20%, Silicon at 0.13–0.45%, Phosphorus capped at 0.025%, and Sulfur limited to 0.010%. It also contains trace elements like Nickel, Chromium, and Copper, which enhance its strength and toughness. This steel offers a tensile strength ranging from 450 to 585 MPa and a minimum yield strength of 240 MPa. It excels in ductility, fracture resistance, and notch toughness, making it an excellent choice for pressure-containing equipment. Plus, its great weldability simplifies forming and fabrication for various industrial applications.
ASME SA 516 Gr.65 Plate Specifications
| Property | Specification |
|---|---|
| Standard | ASME SA 516 |
| Grade | 65 |
| Thickness Range | 6 mm to 200 mm (varies by stockist) |
| Product Form | Plates |
| Condition | As Rolled / Normalized / Stress Relieved |
| Tensile Strength | 450 – 585 MPa |
| Yield Strength | Minimum 260 MPa |
| Elongation | Minimum 17–21% (varies with thickness) |
| Impact Test | As required (optional for low-temperature service) |
| Heat Treatment | Normalized (common for improved toughness) |
| Applications | Boilers, pressure vessels, heat exchangers, storage tanks |
ASME SA 516 Gr.65 Plate Chemical Compositions
| Element | Composition (%) |
|---|---|
| Carbon (C) | ≤ 0.23 |
| Manganese (Mn) | 0.85 – 1.20 |
| Silicon (Si) | 0.15 – 0.40 |
| Phosphorus (P) | ≤ 0.025 |
| Sulfur (S) | ≤ 0.025 |
| Chromium (Cr) | ≤ 0.30 |
| Nickel (Ni) | ≤ 0.30 |
| Molybdenum (Mo) | ≤ 0.10 |
| Copper (Cu) | ≤ 0.30 |
| Vanadium (V) | ≤ 0.02 |
| Aluminum (Al) | ≤ 0.02 (Residual) |
ASME SA 516 Gr.65 Plate Equivalent Grades
| Standard | Equivalent Grade |
|---|---|
| ASTM | ASTM A516 Grade 65 |
| EN Standard | P295GH |
| DIN Standard | HII / 1.0425 |
| BS Standard | 1501-224-490A/B |
| JIS Standard | JIS G3103 SB65 |
| AFNOR | A42CP / A48CP |
| GOST | 09G2S (Nearest Comparable) |
If You Are Looking To Buy High Quality Pipes, Sheet, Angle, Hollow Section, Flat Product.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Related keywords include ASME SA516 Gr.70 Plates Dubai UAE, SA516 Gr.70N Normalized Plates Sharjah, ASTM A537 Class 1 Pressure Vessel Plates Ajman, ASTM A285 Grade C Tank Steel Plates Jebel Ali, EN 10028 P265GH Pressure Vessel Plates Abu Dhabi, and EN 10028 P355NH Boiler Plates Ras Al Khaimah. These expand search relevance for pressure vessel and heat-resistant steel plate categories.
Stolt Steels is the largest stockist of ASME SA 516 Gr.65 Plate in Dubai, UAE.
Stolt Steels is a trusted stockist, stockist, and supplier of premium-quality steel products in Dubai, UAE, serving diverse industrial sectors with reliable materials and timely delivery. With a strong commitment to excellence, we offer a wide range of pipes, sheets, plates, and other metal solutions designed to meet global standards. Our extensive inventory, expert support, and customer-focused approach make us a preferred partner for companies seeking durable and high-performance steel products. For inquiries or orders, contact us at sales@stoltsteels.com.
Types of ASME SA 516 Gr.65 Plate
Uses of ASME SA 516 Gr.65 Plate
ASME SA 516 Grade 65 is a go-to material in industries that demand high-strength, dependable pressure vessel steel. You’ll find it in boilers, pressure vessels, refinery towers, storage tanks, heat exchangers, separators, steam drums, and gas processing equipment. It’s particularly prevalent in petrochemical plants, oil and gas refineries, fertilizer industries, and power plants, where equipment often faces fluctuating pressure and temperature. Thanks to its toughness, crack resistance, and long service life, this material is perfect for equipment operating in tough conditions, ensuring safety and structural integrity in critical industrial settings.
