Stolt Steel stands out as a top stockist and supplier of ASME SA 516 Grade 70N steel plates in Dubai, UAE. They provide high-quality normalized pressure vessel steel that’s trusted for use in high-temperature and high-pressure situations. This steel is renowned for its impressive mechanical strength, toughness, and weldability, making it a go-to choice in critical industrial sectors. Stolt Steel is committed to adhering to international standards, ensuring that their steel is not only durable but also high-performing, perfect for applications in refineries, petrochemicals, oil and gas, and power generation. With their advanced processing capabilities and dependable supply support, Stolt Steel is a reliable partner for industries that need long-lasting and structurally sound steel solutions.
ASME SA 516 Gr.70N Pressure Vessel Steel Plates Dubai UAE, ASTM A516 Grade 70N Boiler Quality Plates Abu Dhabi, SA516 Gr.70N Carbon Steel Plates Sharjah, Hot Rolled SA516 Grade 70N Steel Plates Ajman, and Normalized SA516 Gr.70N Pressure Vessel Plates Jebel Ali. These keywords target major industrial and petrochemical markets.
Table of Contents
ASME SA516 Gr.70N Low-Temperature Service Plates Ras Al Khaimah, SA516 Grade 70N High Tensile Plates Al Ain, ASTM A516 Gr.70N Boiler Steel Plates United Arab Emirates, Fabrication Ready ASME SA516 Gr.70N Steel Plates Dubai, and Heat-Resistant SA516 Gr.70N Plates Abu Dhabi. These terms highlight strength, reliability, and pressure vessel suitability.
What is ASME SA 516 Gr.70N Plate?
ASME SA 516 Grade 70N features a carbon content of up to 0.27%, manganese ranging from 0.85% to 1.20%, silicon between 0.13% and 0.45%, with phosphorus capped at 0.025% and sulfur at 0.010% max. It also includes micro-alloying elements to boost performance. The mechanical properties showcase a minimum tensile strength of 485–620 MPa and a yield strength of 260 MPa. Normalization enhances its impact resistance, ductility, fracture toughness, and overall structural reliability. This material is known for its excellent weldability and stability during thermal cycling, making it ideal for challenging fabrication and pressure-retaining environments.
ASME SA 516 Gr.70N Plate Specifications
| Property / Specification | Details |
|---|---|
| Standard | ASME SA 516 |
| Grade | Grade 70N (Normalized Condition) |
| Product Type | Pressure Vessel Quality Carbon Steel Plates |
| Delivery Condition | Normalized (N) |
| Thickness Range | 5 mm – 200 mm (varies by mill) |
| Tensile Strength | 485 – 620 MPa |
| Yield Strength | ≥ 260 MPa |
| Elongation | ≥ 17–21% (depending on thickness) |
| Impact Test | Optional / As required (Charpy V-Notch) |
| Heat Treatment | Normalized at 900–950°C |
| Applications | Boilers, Pressure Vessels, Heat Exchangers, Oil & Gas Equipment |
ASME SA 516 Gr.70N Plate Chemical Compositions
| Element | Composition (%) |
|---|---|
| Carbon (C) | ≤ 0.27 |
| Manganese (Mn) | 0.85 – 1.20 |
| Silicon (Si) | 0.15 – 0.40 |
| Phosphorus (P) | ≤ 0.025 |
| Sulfur (S) | ≤ 0.025 |
| Chromium (Cr) | ≤ 0.30 |
| Nickel (Ni) | ≤ 0.30 |
| Molybdenum (Mo) | ≤ 0.10 |
| Vanadium (V) | ≤ 0.02 |
| Copper (Cu) | ≤ 0.30 |
| Nitrogen (N) | Normalized condition |
ASME SA 516 Gr.70N Plate Equivalent Grades
| Standard / Specification | Equivalent Grade |
|---|---|
| ASME Standard | SA 516 Grade 70N |
| ASTM Standard | ASTM A516 Grade 70 Normalized |
| EN Standard | P355GH |
| DIN Standard | 17Mn4 / 1.0425 (Closest Equivalent) |
| BS Standard | 1501-224-490B LT50 |
| AFNOR | A52CP / A48CP |
| JIS Standard | JIS G3103 SB480 |
| GOST (Nearest Comparable) | 09G2S |
If You Are Looking To Buy High Quality Pipes, Sheet, Angle, Hollow Section, Flat Product.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Related keywords include ASME SA516 Gr.60 Plates Dubai UAE, ASTM A516 Gr.65 Boiler Plates Sharjah, ASTM A537 Class 1 Pressure Vessel Plates Ajman, ASTM A285 Grade C Tank Plates Jebel Ali, EN 10028 P355NH Pressure Vessel Plates Abu Dhabi, and A204 Alloy Steel Plates Ras Al Khaimah. These help target connected high-temperature and pressure-grade steel plate requirements.
Stolt Steels is the largest stockist of ASME SA 516 Gr.70N Plate in Dubai, UAE.
Stolt Steels is a trusted stockist, stockist, and supplier of premium-quality steel products in Dubai, UAE, serving diverse industrial sectors with reliable materials and timely delivery. With a strong commitment to excellence, we offer a wide range of pipes, sheets, plates, and other metal solutions designed to meet global standards. Our extensive inventory, expert support, and customer-focused approach make us a preferred partner for companies seeking durable and high-performance steel products. For inquiries or orders, contact us at sales@stoltsteels.com.
Types of ASME SA 516 Gr.70N Plate
Uses of ASME SA 516 Gr.70N Plate
ASME SA 516 Grade 70N is commonly used in high-pressure and high-temperature industrial settings. It’s the preferred choice for crafting pressure vessels, boilers, steam drums, heat exchangers, storage tanks, refinery components, and gas processing systems. This steel excels in environments that experience high temperatures and fluctuating internal pressures, making it suitable for oil and gas refineries, petrochemical plants, chemical facilities, fertilizer units, and power stations. Its long service life, strength, and resistance to brittle fracture make it an outstanding material for critical industrial equipment that demands superior safety and durability.
