S355 JR plates Stockist and Supplier in Dubai, UAE
Home> Flat Product > S355 JR plates
S355 JR plates are popular structural steel plates celebrated for their impressive strength, reliability, and impact resistance at room temperature. They boast great weldability, machinability, and toughness, making them a go-to option in the construction, engineering, and fabrication sectors. Manufactured to adhere to strict European standards, these plates consistently perform well in demanding structural applications. Their versatility means they can be utilized across various industries that need durable, high-quality steel components.
Looking for S355 JR Plates in Dubai, UAE? We’ve got you covered with EN 10025 S355 JR Structural Steel Plates in Abu Dhabi, Hot Rolled S355 JR Grade Plates in Sharjah, and High Tensile S355 JR Plates in Ajman. These keywords are perfect for targeting key industrial areas throughout the UAE.
Table of Contents
You can also find S355 JR Structural Plates in Ras Al Khaimah, S355 JR Mild Steel Plates in Al Ain, and S355 JR High-Strength Plates across the United Arab Emirates. Plus, we offer Weldable S355 JR Plates in Dubai and S355 JR HR Steel Plates in Abu Dhabi. These terms really emphasize the suitability for fabrication and availability in the region.
What is S355 JR plates?
These plates are made up of carbon, manganese, silicon, phosphorus, sulfur, and a few trace micro-alloying elements that boost their strength and mechanical stability. With a minimum yield strength of 355 MPa, they also provide solid tensile strength, dependable hardness, and structural integrity. Their well-balanced chemical composition ensures excellent weldability and formability, allowing for shaping and fabrication without sacrificing durability. These characteristics make S355 JR plates ideal for a wide array of load-bearing applications.
S355 JR plates Specifications
| Specification Item | Details |
|---|---|
| Grade | S355 JR |
| Standard | EN 10025-2 |
| Minimum Yield Strength | 355 MPa (up to 16 mm thickness) |
| Tensile Strength | 470 – 630 MPa |
| Impact Test Requirement | 27 Joules @ +20°C (JR grade) |
| Delivery Condition | As-rolled / Normalized / Normalized Rolled |
| Thickness Range | 3 mm – 200 mm (varies by stockist) |
| Width | 1000 mm – 3000 mm |
| Length | 3000 mm – 12000 mm |
| Material Type | High tensile structural steel |
| Weldability | Excellent (low carbon equivalent) |
| Surface Condition | Mill finish, shot blasted, or coated |
| Standards Compliance | EN 10025 structural steel requirements |
| Applications | Construction, bridges, buildings, offshore structures, machinery |
S355 JR plates Chemical Compositions
| Element | Percentage (%) |
|---|---|
| Carbon (C) | ≤ 0.24 |
| Silicon (Si) | ≤ 0.55 |
| Manganese (Mn) | 1.00 – 1.60 |
| Phosphorus (P) | ≤ 0.025 |
| Sulfur (S) | ≤ 0.025 |
| Nitrogen (N) | ≤ 0.012 |
| Copper (Cu) | ≤ 0.55 |
| Chromium (Cr) | ≤ 0.30 |
| Nickel (Ni) | ≤ 0.30 |
| Molybdenum (Mo) | ≤ 0.10 |
| Aluminium (Al) | ≥ 0.015 (for deoxidation) |
| Carbon Equivalent (CEV) | ≤ 0.45 (depending on thickness) |
S355 JR plates Equivalent Grades
| Standard | Equivalent Grade |
|---|---|
| EN 10025-2 | S355J0 / S355J2 (not exact but close variants with different impact requirements) |
| DIN | St52-3 / 1.0570 |
| ASTM / ASME | ASTM A572 Grade 50 (approximate equivalent) |
| BS (British Standard) | 50B / 50C |
| JIS | SM490A |
| ISO | E355 |
| NFA (AFNOR) | E355R |
| GOST (Russia) | 17G1S |
If You Are Looking To Buy High Quality Pipes, Sheet, Fittings and Flanges
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Don’t miss out on related products like S355J2 Plates in Dubai, S355J2+N High Tensile Plates in Sharjah, S355K2 Structural Plates in Ajman, S275JR Carbon Steel Plates in Jebel Ali, Offshore Quality Steel Plates in Abu Dhabi, and EN 10025 Structural Steel Plates in Ras Al Khaimah. These keywords help broaden your reach across similar categories of steel plates.
Stolt Steels is the largest stockist of S355 JR plates in Dubai, UAE.
Stolt Steels is a trusted stockist, stockist, and supplier of premium-quality steel products in Dubai, UAE, serving diverse industrial sectors with reliable materials and timely delivery. With a strong commitment to excellence, we offer a wide range of pipes, sheets, plates, and other metal solutions designed to meet global standards. Our extensive inventory, expert support, and customer-focused approach make us a preferred partner for companies seeking durable and high-performance steel products. For inquiries or orders, contact us at sales@stoltsteels.com.
Types of S355 JR plates
Uses of S355 JR plates
You’ll often find S355 JR plates in building structures, bridges, transport equipment, and offshore constructions, thanks to their strong load-bearing capacity and structural reliability. They’re perfect for crafting frames, support beams, heavy machinery parts, industrial platforms, and infrastructure components. Their toughness at room temperature makes them suitable for general engineering tasks, while their workability ensures efficient fabrication. These plates are also favored in the energy, mining, and automotive industries, where consistent strength and performance are crucial.
