ABS A Shipbuilding Steel Plates Stockist and Supplier in Dubai, UAE
Home > ABS A Shipbuilding Steel Plates
Stolt Steel has established itself as a reliable Stockist and supplier based in Dubai, UAE, specializing in high-quality ABS Grade A shipbuilding steel plates for a variety of marine applications. These plates are crafted in accordance with the standards set by the American Bureau of Shipping (ABS), making them a popular choice for general ship construction thanks to their impressive strength, excellent weldability, and dependable performance in typical marine conditions. Stolt Steel is committed to maintaining rigorous quality control, providing certified materials that ensure both consistency and safety. With a strong focus on efficient logistics and industry know-how, Stolt Steel is here to support shipyards and marine fabricators with trustworthy ABS Grade A steel plates.
ABS A Shipbuilding Steel Plates in UAE, ABS Grade A Ship Steel Plates in Dubai, ABS A Approved Shipbuilding Plates in Abu Dhabi, ABS A Marine Steel Plates in Sharjah, Grade A Shipbuilding Structural Steel Plates in UAE
Table of Contents
ABS A Shipbuilding Steel Plates Supplier in UAE, ABS Grade A Plates Manufacturer in Dubai, ABS A Steel Plates Exporter in Abu Dhabi, ABS A Ship Steel Plates Stockist in Sharjah, ABS A Plates Distributor in UAE.
What is ABS A Shipbuilding Steel Plates?
When it comes to the production of ABS Grade A shipbuilding steel plates, low-carbon steel is used, featuring a carefully controlled chemical composition that guarantees good formability and weldability. Typically, this composition includes carbon levels up to 0.21%, manganese up to 2.50%, silicon up to 0.50%, along with minimal amounts of phosphorus and sulfur. In terms of mechanical properties, ABS Grade A plates boast a minimum yield strength of about 235 MPa and a tensile strength that usually falls between 400 and 520 MPa, along with good elongation, making them ideal for standard structural needs in shipbuilding.
ABS A Shipbuilding Steel Plates Specifications
| Parameter | Specification |
|---|---|
| Standard | ABS A131 |
| Grade | A |
| Product Form | Steel Plates |
| Type | Mild Shipbuilding Structural Steel |
| Heat Treatment | As Rolled / Normalized |
| Minimum Yield Strength | 235 MPa |
| Tensile Strength | 400 – 520 MPa |
| Minimum Elongation | ≥ 22% |
| Impact Test Requirement | Not mandatory (generally not required) |
| Carbon (C) | ≤ 0.21% |
| Manganese (Mn) | 0.60 – 1.60% |
| Silicon (Si) | ≤ 0.50% |
| Phosphorus (P) | ≤ 0.035% |
| Sulfur (S) | ≤ 0.035% |
| Aluminum (Al) | ≥ 0.015% |
| Thickness Range | 4 mm – 150 mm |
| Width Range | 1,200 mm – 3,500 mm |
| Length Range | 3,000 mm – 18,000 mm |
| Certification | ABS Mill Test Certificate |
| Applications | Ship hull structures, decks, bulkheads, general ship construction |
ABS A Shipbuilding Steel Plates Chemical Compositions
| Element | Composition (%) |
|---|---|
| Carbon (C) | ≤ 0.21 |
| Manganese (Mn) | 0.60 – 1.60 |
| Silicon (Si) | ≤ 0.50 |
| Phosphorus (P) | ≤ 0.035 |
| Sulfur (S) | ≤ 0.035 |
| Aluminum (Al) | ≥ 0.015 |
| Copper (Cu) | ≤ 0.35 |
| Nickel (Ni) | ≤ 0.40 |
| Chromium (Cr) | ≤ 0.20 |
| Molybdenum (Mo) | ≤ 0.08 |
ABS A Shipbuilding Steel Plates Equivalent Grades
| Standard / Classification Society | Equivalent Grade |
|---|---|
| ABS (American Bureau of Shipping) | Grade A |
| ASTM / ASME | ASTM A131 Grade A |
| Lloyd’s Register (LR) | LR Grade A |
| DNV (Det Norske Veritas) | DNV Grade A |
| Bureau Veritas (BV) | BV Grade A |
| CCS (China Classification Society) | CCS Grade A |
| KR (Korean Register) | KR Grade A |
| NK (Nippon Kaiji Kyokai) | NK Grade A |
| RINA (Italian Register) | RINA Grade A |
| IRS (Indian Register of Shipping) | IRS Grade A |
| EN (European Standard – approximate) | EN 10025 S235JR (closest match) |
If You Are Looking To Buy High Quality Pipes, Sheet, Fittings and Flanges
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
ABS A Shipbuilding Steel Plates Price in UAE, ABS Grade A Plates Price List in Dubai, ABS A Ship Steel Plates Thickness in Abu Dhabi, ABS A Plates Sizes in Sharjah, ABS A Marine Steel Plates for Shipyard in UAE
Stolt Steels is the largest stockist of ABS A Shipbuilding Steel Plates in Dubai, UAE.
Stolt Steels is a trusted stockist, stockist, and supplier of premium-quality steel products in Dubai, UAE, serving diverse industrial sectors with reliable materials and timely delivery. With a strong commitment to excellence, we offer a wide range of pipes, fittings, flanges, fasteners, sheets, plates, and other metal solutions designed to meet global standards. Our extensive inventory, expert support, and customer-focused approach make us a preferred partner for companies seeking durable and high-performance steel products. For inquiries or orders, contact us at sales@stoltsteels.com.
Types of ABS A Shipbuilding Steel Plates
Uses of ABS A Shipbuilding Steel Plates
These ABS Grade A shipbuilding steel plates are frequently utilized in constructing hull structures, decks, bulkheads, and other essential structural components of ships. They are well-suited for vessels operating in typical temperature marine environments, including cargo ships, bulk carriers, and general-purpose vessels. Thanks to their outstanding weldability and ease of fabrication, ABS Grade A plates are also a go-to choice for ship repairs and marine structural fabrication. These plates guarantee durability, structural integrity, and adherence to international marine classification standards.
