ABS D Shipbuilding Steel Plates Stockist and Supplier in Dubai, UAE
Home > ABS D Shipbuilding Steel Plates
Stolt Steel has established itself as a reliable manufacturer and supplier based in Dubai, UAE, specializing in high-quality ABS Grade D shipbuilding steel plates tailored for marine and offshore applications. These plates are crafted in line with the standards set by the American Bureau of Shipping (ABS), ensuring they deliver enhanced toughness compared to Grades A and B, particularly in colder temperatures. Stolt Steel is committed to rigorous quality control, certified inspections, and dependable supply chains to meet the needs of shipyards and marine fabricators. With a wealth of technical expertise and efficient logistics, Stolt Steel provides ABS Grade D steel plates that are perfect for safe and durable shipbuilding projects.
ABS D Shipbuilding Steel Platesin UAE, ABS Grade D Ship Steel Plates in Dubai, ABS D Approved Shipbuilding Plates in Abu Dhabi, ABS D Marine Steel Plates in Sharjah, Grade D Shipbuilding Structural Steel Plates in UAE
Table of Contents
ABS D Shipbuilding Steel Plates Supplier in UAE, ABS Grade D Plates Manufacturer in Dubai, ABS D Steel Plates Exporter in Abu Dhabi, ABS D Ship Steel Plates Stockist in Sharjah, ABS D Plates Distributor in UAE
What is ABS D Shipbuilding Steel Plates?
The ABS Grade D shipbuilding steel plates are made from low-carbon steel, featuring a precisely controlled chemical composition that boosts both strength and toughness. Typically, the composition includes carbon levels up to 0.21%, manganese up to 2.50%, silicon up to 0.50%, and minimal amounts of phosphorus and sulfur, which contribute to excellent weldability and ductility. In terms of mechanical properties, ABS D plates boast a minimum yield strength of around 235 MPa and tensile strength that ranges from 400 to 520 MPa, along with superior impact resistance in lower temperature conditions.
ABS D Shipbuilding Steel Plates Specifications
| Parameter | Specification |
|---|---|
| Standard | ABS A131 |
| Grade | D |
| Product Form | Steel Plates |
| Type | Mild Shipbuilding Structural Steel |
| Heat Treatment | As Rolled / Normalized |
| Minimum Yield Strength | 235 MPa |
| Tensile Strength | 400 – 520 MPa |
| Minimum Elongation | ≥ 22% |
| Impact Test Temperature | −20 °C |
| Impact Energy (Charpy V) | ≥ 34 J |
| Carbon (C) | ≤ 0.21% |
| Manganese (Mn) | 0.60 – 1.60% |
| Silicon (Si) | ≤ 0.50% |
| Phosphorus (P) | ≤ 0.035% |
| Sulfur (S) | ≤ 0.035% |
| Aluminum (Al) | ≥ 0.015% |
| Thickness Range | 4 mm – 150 mm |
| Width Range | 1,200 mm – 3,500 mm |
| Length Range | 3,000 mm – 18,000 mm |
| Certification | ABS Mill Test Certificate |
| Applications | Ship hulls, decks, offshore and low-temperature marine structures |
ABS D Shipbuilding Steel Plates Chemical Compositions
| Element | Composition (%) |
|---|---|
| Carbon (C) | ≤ 0.21 |
| Manganese (Mn) | 0.60 – 1.60 |
| Silicon (Si) | ≤ 0.50 |
| Phosphorus (P) | ≤ 0.035 |
| Sulfur (S) | ≤ 0.035 |
| Aluminum (Al) | ≥ 0.015 |
| Copper (Cu) | ≤ 0.35 |
| Nickel (Ni) | ≤ 0.40 |
| Chromium (Cr) | ≤ 0.20 |
| Molybdenum (Mo) | ≤ 0.08 |
ABS D Shipbuilding Steel Plates Equivalent Grades
| Standard / Classification Society | Equivalent Grade |
|---|---|
| ABS (American Bureau of Shipping) | Grade D |
| ASTM / ASME | ASTM A131 Grade D |
| Lloyd’s Register (LR) | LR Grade D |
| DNV (Det Norske Veritas) | DNV Grade D |
| Bureau Veritas (BV) | BV Grade D |
| CCS (China Classification Society) | CCS Grade D |
| KR (Korean Register) | KR Grade D |
| NK (Nippon Kaiji Kyokai) | NK Grade D |
| RINA (Italian Register) | RINA Grade D |
| IRS (Indian Register of Shipping) | IRS Grade D |
| EN (European Standard – approximate) | EN 10025 S275JR / S275J2 (closest match) |
If You Are Looking To Buy High Quality Pipes, Sheet, Fittings and Flanges
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
ABS D Shipbuilding Steel Plates Price in UAE, ABS Grade D Plates Price List in Dubai, ABS D Ship Steel Plates Thickness in Abu Dhabi, ABS D Plates Sizes in Sharjah, ABS D Marine Steel Plates for Shipyard in UAE
Stolt Steels is the largest stockist of ABS D Shipbuilding Steel Plates in Dubai, UAE.
Stolt Steels is a trusted stockist, stockist, and supplier of premium-quality steel products in Dubai, UAE, serving diverse industrial sectors with reliable materials and timely delivery. With a strong commitment to excellence, we offer a wide range of pipes, fittings, flanges, fasteners, sheets, plates, and other metal solutions designed to meet global standards. Our extensive inventory, expert support, and customer-focused approach make us a preferred partner for companies seeking durable and high-performance steel products. For inquiries or orders, contact us at sales@stoltsteels.com.
Types of ABS D Shipbuilding Steel Plates
Uses of ABS D Shipbuilding Steel Plates
These ABS Grade D shipbuilding steel plates find extensive use in constructing ship hulls, decks, bulkheads, and other key structural components where enhanced toughness is essential. They are particularly suited for vessels that operate in moderately cold marine environments, including cargo ships, bulk carriers, and tankers. The material’s excellent weldability and improved impact resistance make it a top choice for fabrication and repair tasks. Additionally, ABS Grade D plates are utilized in offshore and marine structural projects, ensuring durability, safety, and adherence to international ship classification standards.
