Stolt Steel stands out as a top manufacturer and supplier based in Dubai, UAE, specializing in high-quality ABS EH36 shipbuilding steel plates designed for tough marine and offshore applications. These plates are crafted to meet the rigorous standards set by the American Bureau of Shipping (ABS), ensuring they deliver exceptional strength, impressive toughness, and reliable performance even in the harshest marine environments. Stolt Steel is committed to maintaining strict quality assurance protocols, providing fully certified materials that align with international shipbuilding standards. With a wealth of technical expertise and efficient logistics, Stolt Steel is dedicated to supporting shipyards and marine fabricators with consistent and trustworthy ABS EH36 steel plate solutions.
ABS EH36 Shipbuilding Steel Plates in UAE, ABS EH36 Ship Steel Plates in Dubai, EH36 ABS Approved Shipbuilding Plates in Abu Dhabi, ABS EH36 Marine Steel Plates in Sharjah, EH36 Shipbuilding Structural Steel Plates in UAE
Table of Contents
ABS EH36 Shipbuilding Steel Plates Supplier in UAE, ABS EH36 Plates Manufacturer in Dubai, ABS EH36 Steel Plates Exporter in Abu Dhabi, ABS EH36 Ship Steel Plates Stockist in Sharjah, ABS EH36 Plates Distributor in UAE
What is ABS EH36 Shipbuilding Steel Plates?
The ABS EH36 shipbuilding steel plates are made from low-carbon, high-strength steel, featuring a carefully controlled chemical composition. Typically, this includes carbon levels up to 0.18%, manganese ranging from 0.90% to 1.60%, silicon up to 0.50%, and minimal amounts of phosphorus and sulfur, along with trace alloying elements that enhance strength and toughness. In terms of mechanical properties, ABS EH36 plates boast a minimum yield strength of around 355 MPa and tensile strength that varies from 490 to 620 MPa, along with good elongation and excellent resistance to low-temperature impacts.
ABS EH36 Shipbuilding Steel Plates Specifications
| Parameter | Specification |
|---|---|
| Standard | ABS A131 |
| Grade | EH36 |
| Product Form | Steel Plates |
| Type | High Strength Shipbuilding Steel |
| Heat Treatment | Normalized / Thermo-mechanically Controlled Process (TMCP) |
| Minimum Yield Strength | 355 MPa |
| Tensile Strength | 490 – 620 MPa |
| Minimum Elongation | ≥ 21% |
| Impact Test Temperature | −40 °C |
| Impact Energy (Charpy V) | ≥ 34 J (thickness dependent) |
| Carbon (C) | ≤ 0.18% |
| Manganese (Mn) | 0.90 – 1.60% |
| Silicon (Si) | ≤ 0.50% |
| Phosphorus (P) | ≤ 0.035% |
| Sulfur (S) | ≤ 0.035% |
| Aluminum (Al) | ≥ 0.015% |
| Carbon Equivalent (CE) | ≤ 0.40 (approx., thickness dependent) |
| Thickness Range | 4 mm – 250 mm |
| Width Range | 1,200 mm – 4,000 mm |
| Length Range | 3,000 mm – 18,000 mm |
| Certification | ABS Mill Test Certificate |
| Applications | Ship hulls, offshore platforms, ice-class and low-temperature marine structures |
ABS EH36 Shipbuilding Steel Plates Chemical Compositions
| Element | Composition (%) |
|---|---|
| Carbon (C) | ≤ 0.18 |
| Manganese (Mn) | 0.90 – 1.60 |
| Silicon (Si) | ≤ 0.50 |
| Phosphorus (P) | ≤ 0.035 |
| Sulfur (S) | ≤ 0.035 |
| Aluminum (Al) | ≥ 0.015 |
| Copper (Cu) | ≤ 0.35 |
| Nickel (Ni) | ≤ 0.40 |
| Chromium (Cr) | ≤ 0.20 |
| Molybdenum (Mo) | ≤ 0.08 |
| Vanadium (V) | ≤ 0.10 |
| Niobium (Nb) | ≤ 0.05 |
| Titanium (Ti) | ≤ 0.02 |
ABS EH36 Shipbuilding Steel Plates Equivalent Grades
| Standard / Classification Society | Equivalent Grade |
|---|---|
| ABS (American Bureau of Shipping) | EH36 |
| ASTM / ASME | ASTM A131 Grade EH36 |
| Lloyd’s Register (LR) | LR EH36 |
| DNV (Det Norske Veritas) | DNV EH36 |
| Bureau Veritas (BV) | BV EH36 |
| CCS (China Classification Society) | CCS EH36 |
| KR (Korean Register) | KR EH36 |
| NK (Nippon Kaiji Kyokai) | NK EH36 |
| RINA (Italian Register) | RINA EH36 |
| IRS (Indian Register of Shipping) | IRS EH36 |
| EN (European Standard – approximate) | EN 10025 S355ML / S355NL (closest match) |
If You Are Looking To Buy High Quality Pipes, Sheet, Fittings and Flanges
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
ABS EH36 Shipbuilding Steel Plates Price in UAE, ABS EH36 Plates Price List in Dubai, ABS EH36 Ship Steel Plates Thickness in Abu Dhabi, ABS EH36 Plates Sizes in Sharjah, ABS EH36 Marine Steel Plates for Shipyard in UAE.
Stolt Steels is the largest stockist of ABS EH36 Shipbuilding Steel Plates in Dubai, UAE.
Stolt Steels is a trusted stockist, stockist, and supplier of premium-quality steel products in Dubai, UAE, serving diverse industrial sectors with reliable materials and timely delivery. With a strong commitment to excellence, we offer a wide range of pipes, fittings, flanges, fasteners, sheets, plates, and other metal solutions designed to meet global standards. Our extensive inventory, expert support, and customer-focused approach make us a preferred partner for companies seeking durable and high-performance steel products. For inquiries or orders, contact us at sales@stoltsteels.com.
Types of ABS EH36 Shipbuilding Steel Plates
Uses of ABS EH36 Shipbuilding Steel Plates
These ABS EH36 shipbuilding steel plates are essential in critical structural areas of ships and offshore structures where high strength and superior toughness are non-negotiable. They are commonly used in hull structures, decks, bulkheads, and longitudinal members of vessels that operate in cold and challenging marine conditions. Their outstanding weldability and ability to withstand impact and dynamic loads make them ideal for container ships, bulk carriers, tankers, and offshore platforms. Additionally, ABS EH36 plates play a vital role in ship repair and heavy marine fabrication projects, ensuring durability, safety, and adherence to international marine classification standards.
